Published on 2025-11-18 by Jose Falanga
If you are looking for a guide on how to configure caddy-fail2ban module, you are in the wrong place. This approach uses no extra modules, and requires both Fail2Ban and Caddy to be installed on your host (no docker/container). You can use docker for everything else.
This doesn’t mean you cannot use containers for this at all (you will notice using volumes smartly can totally allow this workflow), but I’m choosing this setup because it is more straightforward for newcomers, as we won’t delve into docker details.
That said, let’s start dissecting this.
Well, can’t do justice to the absolute beast Caddy is, but you can go
check their Website and their Docs. In short, I’m using Caddy
as a reverse proxy and access point for all my self-hosted services.
Caddy manages redirecting stuff to the appropriate containers, depending
on which domain the request comes in from. This means that I can set
something.thergic.ar regular 80 port to be
forwarded to some internal docker port. It also magically manages SSL
certificates through Let’s
Encrypt, so it also redirects stuff through 443, no
extra setup needed. It’s not that certbot is hard to use,
but Caddy makes the whole thing trivial. It can also be set up to create
wildcard certificates. It can do way more than that, and I’ll probably
expand on this later, but that’s what I’ve got so far.
Their own github readme starts with a pretty good definition:
Fail2Ban: ban hosts that cause multiple authentication errors
Just installing it protects you from SSH brute-forcing, and many other common threats. But here is the thing, it is amazingly flexible because it depends on monitoring logs. So you can introduce new configurations for everything that is being logged in your host.
Well, we can totally make those interact! Main idea is, Caddy logs stuff, Fail2Ban ingests those, and bans bots and crawlers.
Caddy logs include the HTTP code each service assigns to their response. So I had an idea for my first rule. Crawlers poll your routes and paths in an attempt to grab exposed stuff, so they get a lot of 404s. Brute force attacks to login pages will end up in a lot of 401s or 403s, rate limiting is 429. You get the idea, bad-faith actors will trigger a lot of 4xx errors, within short time windows.
First, go and pick an install method. I’m
using plain debian, so I went with the apt option:
sudo apt install caddy
sudo systemctl enable --now caddyI will use the Caddyfile to achieve all my goals. I will not delve too deep into this, you can go to Caddyfile docs for an in-depth explanation and examples of its structure and supported syntax and cases.
Your Caddyfile usually sits at /etc/caddy/Caddyfile. I
like to create a symlink in the home dir for easy access:
sudo ln -s /etc/caddy/Caddyfile ~/So we edit it:
sudo nano ~/CaddyfileThis is what mine looked like (actual domain names replaced):
subdomain.thergic.ar {
reverse_proxy localhost:1234
}
this.isanother.domain {
reverse_proxy localhost:2345
}
notallowed.access.com {
respond 404
}Just with that, Caddy is already redirecting stuff and managing SSL certs. Amazing, right? So, now I’m going to introduce this block for all domains:
log {
output file /var/log/caddy/access.log
format console
}The format option is important so Fail2Ban can properly
parse this with the regex as a single line.
This also can be configured globally, but I wanted to make it case by case, so I can keep my rules flexible. Final Caddyfile looks like this:
subdomain.thergic.ar {
reverse_proxy localhost:1234
log {
output file /var/log/caddy/access.log
format console
}
}
this.isanother.domain {
reverse_proxy localhost:2345
log {
output file /var/log/caddy/access.log
format console
}
}
notallowed.access.com {
respond 404
log {
output file /var/log/caddy/access.log
format console
}
}Save it and reload the caddy service:
sudo systemctl restart caddyOn top of Caddy’s magic, we now have access logs! This is how an actual line looks like:
2025/11/14 04:26:51.951 INFO http.log.access.log1 handled request {"request": {"remote_ip": "195.178.110.201", "remote_port": "40968", "client_ip": "195.178.110.201", "proto": "HTTP/1.1", "method": "GET", "host": "subdomain.thergic.ar", "uri": "/.env", "headers": {"Accept-Encoding": ["gzip, deflate"], "User-Agent": ["Python/3.10 aiohttp/3.13.1"], "Cookie": ["REDACTED"], "Accept": ["*/*"]}, "tls": {"resumed": false, "version": 772, "cipher_suite": 4865, "proto": "http/1.1", "server_name": "subdomain.thergic.ar"}}, "bytes_read": 0, "user_id": "", "duration": 0.010455752, "size": 11, "status": 404, "resp_headers": {"Content-Length": ["11"], "Cache-Control": ["max-age=0, private, must-revalidate, no-transform"], "Content-Type": ["text/plain;charset=utf-8"], "X-Content-Type-Options": ["nosniff"], "X-Frame-Options": ["SAMEORIGIN"], "Via": ["1.1 Caddy"], "Alt-Svc": ["h3=\":443\"; ma=2592000"], "Date": ["Fri, 14 Nov 2025 04:26:51 GMT"]}}Look at that! This crawler is hunting for my server secrets! Note
it’s trying to access /.env, the user agent is Python
(sucker didn’t even try to spoof it). This is an actual attack an actual
bot did to my server.
And the magic sections are
"remote_ip": "195.178.110.201", and
"status": 404. This means we know WHO this person
is, and WHAT the wrongdoing is. Let’s configure Fail2Ban to put
this sucker into bot jail.
sudo apt install fail2ban caddy
sudo systemctl enable --now fail2banThat already enabled a lot of different protections for your server.
One of the most useful is sshd. Don’t get me wrong, you
shouldn’t expose your SSH to the open internet. If you do, then you
should disable password access and only use ssh authorized keys. But if
you are stubborn enough to not follow any of that advice, then fail2ban
already got your back.
Wanna try it? Execute this:
watch sudo fail2ban-client status sshdThat will output something like this and update every 2 seconds:
Status for the jail: sshd
|- Filter
| |- Currently failed: 0
| |- Total failed: 0
| `- File list: /var/log/auth.log
`- Actions
|- Currently banned: 0
|- Total banned: 0
`- Banned IP list: Now open another terminal, and fail to login with ssh. You will see
the count going up in real time. Now stop doing that, you are going to
get yourself banned! Fail2Ban will add an iptables rule and
you will be out.
Well, as Minecraft is the sum of Mine and Craft, Fail2Ban needs Fails and Ban (rules) to work. Let’s start with the fails. We are going to create a new filter:
sudo nano /etc/fail2ban/filter.d/caddy-400.confAnd inside we paste the following:
[Definition]
failregex = ^.*"remote_ip": "<HOST>".*"status": 4[0-9][0-9]
ignoreregex =This regex will match anything in the range of 4xx. You can opt to only match some, but for me, every bad request is an offense. I’m not including 5xx here, as they only denote the service malfunctioning. If I detect in the future some bad-faith actor making my services crash on purpose, I can totally add another filter for that.
Now, let’s create a jail for the bans:
sudo nano /etc/fail2ban/jail.d/caddy-400.confContents example:
[caddy-400]
enabled = true
logpath = /var/log/caddy/access.log
maxretry = 10
findtime = 60
bantime = 36000Explanation:
maxretry: how many fails are allowed? Just 10findtime: how far in the past I need to look? 1
minutebantime: how much time the ban will last? 10 hoursSo, if your python bot triggers 10 4xx errors across any of my
services within a minute, you are officially in jail. You can adjust
this to tighten or loosen the limits. The idea is to only capture
bad-faith actors and not ban human users on accident, so you need to
tune for false positives. It is hard for humans to make 10 offenses in 1
minute, usually bots do it, as they operate in fast bursts. If you want
to also handle slow crawlers, you need to either increase the
findtime or decrease the maxretry, or
both.
Reload the service:
sudo systemctl restart fail2banYou can check the jail status with:
sudo fail2ban-client status caddy-400Outputs:
Status for the jail: caddy-400
|- Filter
| |- Currently failed: 4
| |- Total failed: 6
| `- File list: /var/log/caddy/access.log
`- Actions
|- Currently banned: 0
|- Total banned: 0
`- Banned IP list: That’s it!
If you use APIs or frontend SPAs that make lots of failing requests,
consider raising maxretry or excluding their IPs.
If you need to unban someone (maybe yourself), use:
sudo fail2ban-client set caddy-400 unbanip <IP>This can probably be improved. You could get email alerts when fail2ban acts if you like. I didn’t configure that, so I’m using this to monitor bans manually after the fact:
sudo cat /var/log/fail2ban.log.1 | grep BanThat outputs something like:
[date] fail2ban.actions [708]: NOTICE [caddy-400] Ban 195.178.110.201
[date] fail2ban.actions [709]: NOTICE [caddy-400] Ban 16.171.237.119
[date] fail2ban.actions [709]: NOTICE [caddy-400] Ban 13.214.183.227
[date] fail2ban.actions [709]: NOTICE [caddy-400] Ban 195.178.110.201That’s the actual output of my server. And if you are curious about how that happened, you can go to caddy logs and check one particular IP:
sudo cat /var/log/caddy/access.log | grep "195.178.110.201" > attackIf you followed the steps above, your services are now hardened against a lot of common cases and you will not waste CPU, network or any resource that would compromise your services availability. Of course this doesn’t magically solve all cases, and you can still harden your self-hosted stuff. It’s a stepping stone in the right direction.
